Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 155

OPERATORS MANUAL
TM 5-3805-261-10
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) - CONTINUED 0013 00
0013 00-11
22 Before EMS Panel -
Test Switch
Off and
Engine Off
a. Move the EMS Panel test switch to
OFF and check for the following:
(1) Coolant temperature indicator
should be off.
Coolant temperature indica-
tor is on.
(2) Engine oil pressure indicator
should be on.
Engine oil pressure indicator
is off.
(3) Brake air pressure indicator
should be on.
Brake air pressure indicator is
off.
(4) Hydraulic oil temperature
indicator should be off.
Hydraulic oil temperature
indicator is on.
(5) Alternator indicator should be on.
Alternator indicator is off.
(6) Steering indicator should be on.
Steering indicator is off.
(7) Master fault light should be off.
Master fault light is on.
(8) Fault alarm should be off. Fault alarm is on.
23 Before EMS Panel -
Test Switch
Off and
Engine On
a. Start the engine using the Start
Engine procedure in WP 0005 00.
b. With the engine running, check for
the following:
(1) All indicators should be off. An indicator is on.
(2) Master fault light should be
off.
Master fault light is on.
(3) Fault alarm should be off. Fault alarm is on.
24 Before EMS Panel -
Test Switch
On and
Engine On
With the engine running and the EMS
panel test switch on, check for the fol-
lowing:
(1) All indicators should be on. An indicator is off.
(2) Master fault light should be on.
Master fault light is off.
(3) Fault alarm should be on. Fault alarm is off.
25 Before EMS Panel -
Blade Float
(if equipped)
WARNING
Blade must be lowered before turning on the blade float
switch. Failure to follow this warning may result in injury.
With engine running, move the Blade
Float switch to ON. Blade float indi-
cator should be on.
Blade float indicator is off.
ITEM
NO. INTERVAL
MAN-
HOURS
LOCATION
ITEM TO
CHECK/
SERVICE PROCEDURE
NOT FULLY MISSION
CAPABLE IF:
