Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 122

OPERATORS MANUAL
TM 5-3805-261-10
TROUBLESHOOTING PROCEDURES - CONTINUED 0011 00
0011 00-2
EMS FAULT INDICATORS - CONTINUED
1. EMS Coolant Temp Indicator Flashes
During Operation - Continued.
8. Check transmission oil level. If transmission oil level is low, fill
to correct level (WP 0013 00). If
level is okay and problem still
exists, notify Unit Maintenance.
2. EMS Engine Oil Press (psi) Indicator
Flashes During Operation.
CAUTION
When engine oil pressure indicator flashes, immediate shut-
down of machine is required to prevent damage to machine.
Check engine oil level (WP 0013
00)
If engine oil is low, fill to correct
level. If problem still exists,
notify Unit Maintenance.
3. EMS Brake Press (psi) Indicator Flashes
During Operation.
WARNING
When brake air pressure low indicator comes on, bring machine
to a safe stop. Failure to follow this warning may result in
injury.
1. Ensure that air tank drain
valve(s) are closed.
Close drain valve(s) if required. If
problem still exists, go to test step
2.
2. Check for air leaks at air tank,
hoses, fittings, lines, and air
dryer (if equipped).
If any leaks are present or if
problem still exists, notify Unit
Maintenance.
4. EMS Hydraulic Oil Temp Indicator
Flashes During Operation.
1. Check for flashing hydraulic
oil temp indicator during
operation.
Reduce load and continue to
monitor temperature. If indicator
is still flashing, go to test step 2.
2. Allow engine to idle at 960
RPM for 5-10 minutes to cool
down.
If problem still exists, shut down
engine and go to test step 3.
3. Check radiator for debris. Remove debris. If there is
excessive debris, notify Unit
Maintenance. If no debris is
present, go to test step 4.
4. Check system for leaks. If leaks are found, notify Unit
Maintenance. If no leaks are
found, go to test step 5.
5. Check hydraulic oil level (WP
0013 00).
If low, add hydraulic oil (WP
0013 00). If hydraulic oil level is
okay, notify Unit Maintenance.
MALFUNCTION TEST OR INSPECTION CORRECTIVE ACTION
