Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 250

OPERATORS MANUAL
TM 5-3805-261-10
COMPONENTS OF END ITEM (COEI) AND BASIC ISSUE ITEMS (BII) LISTS - CONTINUED 0021 00
0021 00-2
Table 1. Components of End Item List .
(1)
ILLUS
NUMBER
(2)
NATIONAL STOCK
NUMBER
(3)
DESCRIPTION, CAGEC,
AND PART NUMBER
(4)
USABLE
ON CODE
(5)
U/M
(6)
QTY
RQD
1 5306-00-260-4508 BOLT, MACHINE
(11083) 0S1594
AF10, AGM EA 8
2 5995-01-169-7620 CABLE ASSEMBLY, SPECIAL
PURPOSE, ELECTRICAL: Jumper
(11083) 5R7028
AF10, AGM EA 1
3 5340-01-186-3757 CAP, PROTECTIVE, DUST AND
MOISTURE SEAL
(15819) 625-2-701-89
AF10, AGM EA 3
4 CAP (Wiring Harness)
(11083) 5R6220
AF10, AGM EA 1
5 CAP (Wiring Harness)
(11083) 6V1824
EA 2
6 CAP (Wiring Harness)
(11083) 6V1830
AF10, AGM EA 2
7 CAP (Wiring Harness)
(11083) 6V1827
AF10, AGM EA 1
8 CAP (Wiring Harness)
(11083) 5P8922
AF10, AGM EA 1
9 2520-01-201-4146 EXTRACTOR ASSEMBLY, CABLE
(11083) 5R7047
AF10, AGM EA 1
10 GUARD ASSEMBLY
(11083) 5R7072
AF10, AGM EA 1
11 4720-01-169-2659 HOSE ASSEMBLY, NONMETALLIC:
Jumper (Return)
(11083) 5R6910
AF10, AGM EA 1
12 4720-01-169-9603 HOSE ASSEMBLY, NONMETALLIC:
Jumper (Supply)
(11083) 5R6909
AF10, AGM EA 1
13 2590-01-168-0025 JACK, LEVELING-SUPPORT
(11083) 3G2468
AF10, AGM EA 2
14 5340-01-293-1047 PLATE, MENDING: Lock Bar, Hydraulic
Pump Drive Shaft
(11083) 5R7075
AF10, AGM EA 1
15 5935-01-170-7691 PLUG, END SEAL, ELECTRICAL
CONNECTOR: Governor and Transmission
AF10, AGM EA 3
16 PLUG: Wiring Harness
(11083) 5R6221
AF10, AGM EA 1
