Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 204

OPERATORS MANUAL
TM 5-3805-261-10
SECTIONALIZATION FOR AIR TRANSPORT INTRODUCTION - CONTINUED 0018 00
0018 00-2
TOOLS AND EQUIPMENT
1. Tools and equipment required for sectionalization are stored in a tool box located on the front of the machine.
2. BII tools (WP 0021 00) must also be used.
3. The following table contains wrench sizes that are needed to complete the sectionalization procedure.
END OF WORK PACKAGE
Location
Bolt/Nut
Size Wrench Size
Pump drive shaft guard bolts 3/8-16
1/2-13
9/16
3/4
Pump drive shaft bolts 3/8-16
3/8-24
9/16
9/16
Upper articulation pin outer bolts 1/2-13 3/4
Lower articulation pin bottom cap bolts 5/8-11 15/16
Lower articulation pin outer bolts 1/2-13 3/4
Lower articulation pin retainer bolts 1/2-13 3/4
Articulation pin pusher bolts 1/2-13 3/4
Articulation cylinder pin cap bolts 3/8-24 9/16
Front frame cable clamp bolts 3/8-16 9/16
Remote control box storage attaching bolts 5/16-18 1/2
Solid tandem link cap bolts 3/8-16 9/16
Push-pull cable nuts 3/8
1/2
15/16
1
Bolt-on eyes 3/4-10 -
