Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 185

OPERATORS MANUAL
TM 5-3805-261-10
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) - CONTINUED 0013 00
0013 00-41
105 Monthly All Systems -
Machine
Exercise
CAUTION
DO NOT perform this PMCS exercise when temperature is
below 0°F (-18°C).
NOTE
DO NOT exercise machine if it has been operated within the
past month.
a. Perform Before operation PMCS.
b. Start and warm up engine (WP
0005 00).
c. While machine is warming up,
perform a walkaround inspection,
checking for evidence of leaks.
Class III oil or hydraulic leaks
are evident. Any fuel or cool-
ant leaks are evident.
NOTE
If temperature is below 32°F (0°C), operate controls prior to
moving machine.
d. When machine has warmed up,
begin to operate ALL controls
slowly:
(1) Transmission in all ranges
including reverse
(2) Differential lock engaged and
disengaged
(3) Parking and service brakes
applied and released
(4) Steering from full left to full
right
(5) All hydraulic controls (blade,
scarifier, articulation and wheel
lean circuits)
(6) Centershift guide pin
g. Operate controls for another five
minutes.
h. Move machine and operate all
controls through full motion to
bring all systems to operating tem-
perature.
ITEM
NO. INTERVAL
MAN-
HOURS
LOCATION
ITEM TO
CHECK/
SERVICE PROCEDURE
NOT FULLY MISSION
CAPABLE IF:
Previous page
Next page
