Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 180

OPERATORS MANUAL
TM 5-3805-261-10
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) - CONTINUED 0013 00
0013 00-36
97 Weekly Right Bat-
tery Com-
partment
WARNING
• To avoid injury, eye protection and acid-resistant gloves must
be worn when working around batteries. DO NOT smoke, use
open flame, make sparks, or create other ignition sources
around batteries. If a battery is giving off gases, it can explode
and cause injury. Remove all jewelry such as rings, ID tags,
watches, and bracelets. If jewelry or a tool contacts a battery
terminal, a direct short will result in instant heating, damage
to equipment, and injury to personnel.
• Sulfuric acid contained in batteries can cause serious burns. If
battery corrosion or electrolyte makes contact with skin, eyes, or
clothing, take immediate action to stop the corrosive burning
effects. Failure to follow these procedures may cause death or
serious injury to personnel.
• DO NOT use compressed air to clean batteries. Use a clean,
dry rag.
CAUTION
To reduce battery damage, check battery compartment for
corrosion (greenish/white powder) and DO NOT jerk or pull
on battery cables during visual inspection.
a. Remove cover to battery compart-
ment.
b. Check holddown for looseness or
damage.
Holddown is loose or dam-
aged.
c. Inspect battery for a cracked case
and evidence of leaking.
Battery case is cracked or
leaks are evident.
NOTE
If machine is equipped with original equipment maintenance-
free batteries, batteries will have no filler caps.
d. Check for damaged or missing
battery filler caps.
Damaged or missing filler
caps are noted.
e. Check for missing, broken, split,
or frayed battery cables.
Damage is noted.
f. Check for damaged battery posts.
g. Install battery compartment cover.
Damage is noted.
ITEM
NO. INTERVAL
MAN-
HOURS
LOCATION
ITEM TO
CHECK/
SERVICE PROCEDURE
NOT FULLY MISSION
CAPABLE IF:
Previous page
Next page
