Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 166

OPERATORS MANUAL
TM 5-3805-261-10
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) - CONTINUED 0013 00
0013 00-22
64
(Con’t)
d. Locate battery cables that are
routed into engine compartment
from battery compartment. Check
for the following:
(1) Loose, broken, split, or frayed
battery cables
Cables are loose or damaged.
(2) Damaged or missing battery
cable grommets
65 After Engine Air
Precleaner
and Primary
Element
WARNING
• If NBC exposure is suspected, personnel wearing protective
equipment should handle all air cleaner media. Consult your
NBC Officer or NBC NCO for appropriate handling or disposal
procedures.
• NBC contaminated filters must be handled using adequate
precautions and must be disposed of by trained personnel.
a. Clean engine air precleaner if
debris is visible in precleaner (WP
0014 00).
b. Inspect primary element and clean
if necessary (WP 0015 00).
66 After Fuel Tank
Filler Tube
and Fuel
Tank
WARNING
• DO NOT smoke or permit any open flame in area of machine
while you are servicing fuel system. Be sure hose nozzle is
grounded against filler tube during refueling to prevent static
electricity. Failure to follow this warning may cause injury to
personnel or equipment damage.
• Operating personnel must wear fuel-resistant gloves when
handling fuels. If exposed to fuel, promptly wash exposed
skin and change fuel-soaked clothing.
a. Check for damage or fuel leaks
from fuel tank drain valve.
Class III fuel leaks are evi-
dent.
ITEM
NO. INTERVAL
MAN-
HOURS
LOCATION
ITEM TO
CHECK/
SERVICE PROCEDURE
NOT FULLY MISSION
CAPABLE IF:
