Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 161

OPERATORS MANUAL
TM 5-3805-261-10
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) - CONTINUED 0013 00
0013 00-17
LEFT SIDE
AND REAR
WARNING
Improperly inflated tires can cause excessive heat buildup resulting in
blowouts. Failure to follow this warning may cause injury to personnel
or damage to equipment.
48 After Left Front
Wheel and
Tire
a. Visually check left front tire for
cuts or bulges in tread or sidewall
area. Check for uneven wear or
underinflation. Look for foreign
material embedded in tread or
sidewall area. Remove foreign
material if found.
Tire has cuts or bulges in tread
or sidewall area or other dam-
age that would impair opera-
tion.
b. Check for loose or missing lug
nuts or valve stem caps.
Missing two or more lug nuts
or has damaged valve stem.
49 After Steering a. Check steering linkage for cracks,
distortion, or damage.
Cracks or distortion in steer-
ing linkage that would impair
operation.
b. Check left front steering cylinder
and hoses for damage or leaks.
Class III leaks or damage that
would impair operation.
50 After Drawbar a. Check drawbar and drawbar pivot
point for damage.
Class III leaks or damage that
would impair operation.
b. Check all hoses and fittings for
leaks.
51 After Scarifier Check scarifier frame, link rod, and
teeth for excessive wear, damage, or
missing components.
Damage that would impair
operation, or missing six scar-
ifier teeth if required for mis-
sion.
52 After Hydraulic
Cylinders
a. Check scarifier hydraulic cylinder
and hoses for damage or leaks.
Class III leaks or damage that
would impair operation.
b. Check left lift cylinder and hoses
for damage or leaks.
Class III leaks or damage that
would impair operation.
c. Check centershift cylinder and
hoses for damage or leaks.
Class III leaks or damage that
would impair operation.
53 After Circle Drive a. Check all circle drive components
for damage or debris. Remove
debris.
Damage to circle drive that
would impair operation.
b. Check circle drive for damage or
leaks.
Class III leaks or damage that
would impair operation.
ITEM
NO. INTERVAL
MAN-
HOURS
LOCATION
ITEM TO
CHECK/
SERVICE PROCEDURE
NOT FULLY MISSION
CAPABLE IF:
