247, 257, 267, 277 and 287 Multi Terrain Loaders Operation and Maintenance Manual Page 42

Operation and Maintenance Manual
42 SEBU7494-06
Product Information Section
General Information
Table 9
Rated Operating Load with a Utility Fork
Part Number
165-8732 165-8737
Weight 195 kg (430 lb) 217 kg (478 lb)
Width 1676 mm (66 inch) 1829 mm (72 inch)
(B) 314 mm (12 inch) 314 mm (12 inch)
Models
247 R.O.C
35%
420 kg (925 lb) 414 kg (912 lb)
R.O.C
50%
600 kg (1322
lb)
592 kg (1305
lb)
257
R.O.C
35%
628 kg (1384 lb) 622 kg (1371 lb)
R.O.C
50%
897 kg (1977 lb) 889 kg (1959 lb)
267 R.O.C
35%
900 kg (1984 lb) 894 kg (1971 lb)
R.O.C
50%
1286 kg (28
35 lb)
1277 kg (28
15 lb)
277
R.O.C
35%
905 kg (1995 lb) 899 kg (1982 lb)
R.O.C
50%
1293 kg (2851 lb) 1285 kg (2833 lb)
287 R.O.C
35%
976 kg (2151 lb) 967 kg (2131 lb)
R.O.C
50%
1394 kg (30
73 lb)
1381 kg (30
44 lb)
Rated Load with a Ma terial Handling
Arm
Failure to comply to the rated load can cause pos-
sible personal injury or property damage. Review
the rated load of a particular work tool before per-
forming any operation. Make adjustments to the
rated load as necessary for non-standard config-
urations.
Note: Ratedloadsshouldbeusedasaguide.
Attachments, uneven ground conditions, soft ground
conditions, or poor ground conditions have effects on
rated loads. The operator is responsible for being
aware of these effe cts.
The maximum placement height (ground line to the
chain hook) is given for the highest position of the
material handling arm. The maximum reach (front
of the machine to the chain hook) is the maximum
horizontal reach of the material handling arm.
The rated operating capacity is the least amount of
weight of the following conditions:
•
35% of the full static tipping load on a soft, less
smooth or level surface or 50% of the full static
tipping load on a hard, smooth, level surface
•
100% of the lifting capacity
•
The material handling arm has a structural capacity
of 907 kg (2000 lb).
The following tables provide the rated operating
capacities (R.O.C.) for the standard machine
configuration that is equipped with the following
items:
•
full fuel tank
•
75 kg (165 lb) operator
•
Caterpillar Material Handling Arm
