Dozer Blade (29)
These warning messages are located on the back
side of the blade.
g01039066
No clearance for person in this area during oper-
ation. Severe injury or death from crushing could
occur. Stay away from the work tool while it is in
operation.
Dozer Blade (30)
This warning is located on right hand side on the
back of the blade.
g00934493
DO NOT OPERATE OR WORK ON THIS MACHINE
UNLESS YOU HAVE READ AND UNDERSTAND
THE INS
TRUCTIONS AND WARNINGS IN THE
OPERATION AND MAINTENANCE MANUALS.
FAILURE TO FOLLOW THE INSTRUCTIONS OR
HEED TH
E WARNINGS COU LD RESULT IN IN-
JURY OR DEATH. CONTACT ANY CATERPILLAR
DEALER FOR REPLACEMENT MANUALS. PROP -
ER CAR
E IS YOUR RESPONSIBILITY.
Dozer Blade (31)
This warning message is located on top of the dozer
blade.
g00946617
Falling Hazard - Area may be oily and slippery.
Do not step on cylinders. Serious injury or death
could occur from a fall.
Dozer Blade (32)
This warning message is located on top of the dozer
blade.
g00943180
No clear
ance for person in this area during oper-
ation. Severe injury or death from crushing could
occur. Stay away from the work tool while it is in
operat
ion.
