247, 257, 267, 277 and 287 Multi Terrain Loaders Operation and Maintenance Manual Page 20

Operation and Maintenance Manual
20 SEBU7494-06
Safety Section
Safety Messages
Angle Blade (25)
These warning messages are located on the back
side of the blade.
g00943177
No clearance for person in this area during oper-
ation. Severe injury or death from crushing could
occur. Stay away from the work tool while it is in
operation.
Utility Grapple Fork (26)
These warning messages are located on top of the
grapple frame.
g00943178
No clearance for person in this area during oper-
ation. Severe injury or death from crushing could
occur.
Stay away from the work tool while it is in
operation.
Utility Grapple Fork (27)
These warning messages are located on top of the
fork carriage.
g00943179
No clearance for person in this area during op-
eration. Severe injury or death from impalement
could occur. Stay away from the work tool while it
is in operation.
Utility Grapple Bucket (28)
These warning messages are located on top of the
grapple frame.
g00943180
No clearance for person in this area during oper-
ation. Severe injury or death from crushing could
occur.
Stay away from the work tool while it is in
operation.
