Industrial Grapple Bucket (21)
These warning messages are located on top of the
guards for the grapple cylinders.
g00943160
No clearance for person in this area during oper-
ation. Severe injury or death from crushing could
occur. Stay away from the work tool while it is in
operation.
Utility Fork (22)
These warning messages are located on top of the
fork carriage.
g00943161
No clearance for person in this area during op-
eration. Severe injury or death from impalement
could o
ccur. Stay away from the work tool while it
is in ope ration.
Industria l Grapple Fork (23)
These warning messages are located on the guards
for the grapple cylinders.
g00943172
No clearance for person in this area during oper-
ation. Severe injury or death from crushing could
occur. Stay away from the work tool while it is in
operation.
Industria l Grapple Fork (24)
These warning messages are located on top of the
fork carriage.
g00943175
No clearance for person in this area during op-
eration. Severe injury or death from impalement
could o
ccur. Stay away from the work tool while it
is in operation.
