138 SEBU7494-06

Maintenance Section

Track (Rubber) - Remove/Replace

i01947524

Track (Rub ber) -

Remove/Repla

SMCS Code: 4197; 4198-011; 4198-510

Removing the Track 247 and 257

Note: Refer to the table for the tooling that is needed

in order to remove the tracks and install the tracks on

the 247 and 257

machines.

Table 2 3

Required Tools

Part Number Part Description

224-9417 Cap

224-9416

Installation Tool (Wheel)

224-9415 Kit

(1)

The Kit includes the Cap a nd the Installation Tool.

1. Po

sition the machine on firm, level ground.

2. Remove any work tool that is attached to the quick

upler.

3. Raise the loader arms and install the brace

r the loader lift arm. Refer to Operation and

Maintenance Manual, “Loader Lift Arm Brace

Operation”.

4. Use an appropriate floor jack in order to lift the

machine off the ground. Use appropriate jack

tands in order to block up the machine.

5. Detension the track. Refer to Operation

nd Maintenance Manual, “Track (Rubber) -

Inspect/Adjust”.

g00953660

Illustration 177

6. Remove the snap ring (1) and the dust cover (2).

g00953716

Illustration 178

7. Remove the nut (3) and the washer (4).

g00953721

Illustrat

ion 179

8. Thread the cap onto the end of the axle shaft.

Note: If the cap is not installed, the seal on the wheel

will be damaged.

g00953723

Illustration 180
