C27 and C32 Generator Sets Engines Disassembly and Assembly Page 4

Disassembly and Assembly
4 RENR9716 -02
Disassembly and Assembly Section
Disassembly an
d Assembly
Section
i02747487
Engine - Remove
SMCS Code: 100
0-011
Removal Proce
dure
Table 1
Required Tools
Tool
Part
Number Part Description Qty
A
138-7573
Link Bracket 2
B
238-9586
Engine Turnin
gTool
1
C
1U-9200
LeverPullerHoist 1
D 189-0411
Shackle As
2
E
6V-6146
Load Leveling Beam 1
Start By:
a. Remove the cooling package. Refer to
Disassembly and Assembly, “Cooling System
Package (Radiator, Aftercooler, Fuel Cooler) -
Remove”.
g01291159
Illustration 1
1. Disconnec
t hose assembly (1). Disconnect cable
assembly (2). Disconnect harness assemblies
(3). Disconnect cable assembly (4). Disconnect
harness a
ssemblies (5).
g01291160
Illustration 2
2. Disconnect harness assembly (6).
g01291161
Illustration 3
3. Disconnect hose assemblies (7), (8), and (9).
g01291162
Illustration 4
4. Disconnect clamp (10).
