TH360B Telehandler Operation and Maintenance Manual Page 20

Operation and Maintenance Manual
18 31200243
Safety Section
Crushing Hazard (17)
This message is located on both sides of the
multipurpose bucket on the top of the bucket.
g00943172
No clearance for person in this area during operation.
Severe injury or death from crushing could occur. Stay
away from the work tool while it is in operation.
Crushing Hazard (18)
This message is located on both sides of the hopper.
g00951560
No clearance for person in this area during operation.
Severe injury or death from crushing could occur. Stay
away from the work tool while it is in operation.
Operation (19)
This message is located on the left hand cover at the
rear of the broom.
g00984073
Do not operate or work on this equipment unless you
have read and understand the instructions and
warnings in the Operation and Maintenance Manual.
Failure to follow the instructions or heed the warnings
could result in injury or death. Contact any Caterpillar
dealer for replacement manuals. Proper care is your
responsibility.
Impaling Hazard (20)
This message is located on both sides of the grapple
bucket.
g00951569
No clearance for person in this area during operation.
Severe injury or death from impalement could occur.
Stay away from the work tool while it is in operation.
