TH360B Telehandler Operation and Maintenance Manual Page 19

Operation and Maintenance Manual
31200243 17
Safety Section
Jump Start Cables (15)
This safety message is positioned on a bracket next to
the batteries.
g00931020
Explosion Hazard! Improper jumper cable connections
can cause an explosion resulting in serious injury or
death. Batteries may be located in separate
compartments. Refer to the Operation and
Maintenance Manual for the correct jump starting
procedure.
Refer to Operation and Maintenance Manual, "Engine
Starting with Jump Start Cables" for more information.
Ether (16)
This safety message is positioned on the intake for the
air cleaner.
g00931562
Explosion hazard! Do not use ether! This machine is
equipped with an air inlet heater. Using ether can
create explosions or fires that can cause personal
injury or death. Read and follow the starting procedure
in the Operation and Maintenance Manual.
Refer to Operation and Maintenance Manual, "Fire
Prevention and Explosion Prevention" for more
information.
