Caterpillar Engine Tools Cat Overhaul 3512 Page 316

Operation and Maintenance Manual

Page of 420

/ 420

2887504

2887536

3-316

Engine Tools

Fuel System Repair and Adjust

380-8305 Timing Case Cover Alignment Tool

Model Usage: C4.4

Warranty: Six Months

• Usedtocorrectlyalignpressedsteeltimingcasecovertothetimingcase

Specications

Dimensions 150 x 95 x 95 mm (5.9 x 3.7 x 3.7 in)

Material Steel

Weight 0.77 kg (1.7 lb)

Part Number Description

380-8305 TimingCaseCoverAlignmentTool

375-2691 Air in Fuel Sight Gauge

Model Usage: C7.1, C6.6, C4.4

Warranty: Six Months

• Usedintestprocedurestoviewairinfuel

• Quickdisconnectsforeasyinsertionandremoval

• Usedtotemporarilyreplacelow-pressurefuellinetomakeobservation

Part Number Description Dimensions

375-2691 Air in Fuel Sight Gauge 1263 x 119 x 19 mm

(50 x 4.7 x 0.7 in)
