Inspect the material handling arm and the attachments for wear and damage. Ensure that the load is

properly attached to the material handling arm before you operate the machine.

Note: The physical size and the weight of the load determines the lifting point that is appropriate.

Whenever it is possible, use the lifting point 1. This will improve the stability and this will reduce the

movement of the load. Refer to the Operation and Maintenance Manual, "Material Handling Arm Rated

Load" for the limitations on the weight.

Note: Use only Caterpillar 9V-2714 Hook and Caterpillar 9V-2715 Shackle to attach a load to the

material handling arm. Never use an open hook. Use a line that is rated for 2.5 times the weight of the

load.

Do not allow anyone to be near a suspended load unless the

position lock pin is installed. If the lift arms must be raised

to handle a tall load, do not allow anyone to be near the

suspended load unless the lift arms are blocked. Failure to

follow the instructions or heed the warnings could result in

injury or death.

Two Person Operation

Attaching A Load

1. Verify that the load does not exceed the weight limit. Refer to the Operation and Maintenance

Manual, "Material Handling Arm Rated Load" for the rated load capacities.

2. Keep all personnel out of the work area at all times, except when you are attaching or removing a

load.

3. Enter the machine. Start the engine.

4. Disengage the parking brake.

151
