"C" SERIES SKID STEER LOADERS Service Training Meeting Guide Page 7

Service Training Meeting Guide
Ride Control has been added as an option on the Skid Steer Loaders only. The Ride Control
System operates similarly to current Caterpillar wheel loaders.
The optional high flow XPS hydraulic system is now optional on all "C" Series machines.
A creeper control function has been added, which allows the operator to select a maximum
machine travel speed at full joystick movement.
The two-speed function is optional on all machines.
Cat ToughGuard™ hydraulic hoses provide excellent abrasion resistance, which exceeds the
capabilities of standard hydraulic hoses.
The MTL undercarriage has been redesigned with greater serviceability in mind, and when
fitted, the optional Dual Level Suspension utilizes eight independently pivoting bogie axles for
smoother travel.
SERV1833-01 - 7 - Text Reference
07/08
Previous page
Next page
